DS-F22
DS-F22 is an ultra-thin fingerprint time attendance and access control terminal with BioID sensor and Wi-Fi, which offers unparalleled performance with advanced algorithm for reliability, precision and excellent matching speed. DS-F22 features the fastest commercial-based fingerprint matching algorithm and ZK high-performance, high-image quality infrared detection fingerprint sensor. DS-F22 provides a superior touching experience with touch keypad, and offers flexibility for standalone installation or with any third-party access control panel that supports standard wiegand signal. TCP/IP, RS485 and Wi-Fi are also available that the device can be used in different networks.
Features
- Ultra thin and elegant design
- Built-in auxiliary input with enhanced flexibility to link wired detector or switch.
- Standard WIFI
- Multiple Verification Modes
| Name | Details |
| Display | 2.4 inch TFT LCD Color Screen |
| Fingerprint Capacity | 3,000 |
| Card Capacity | 5,000 (optional) ID or MF card |
| Transaction Capacity | 30,000 |
| Fingerprint Sensor | BioID Sensor / SilkID Sensor (optional) |
| Algorithm Version | ZKFinger VX10.0 |
| Communication | RS232/485, TCP/IP USB host, WIFI |
| Access Control Interface | 3rd Party Electric Lock, Door Sensor, Exit button, Alarm |
| Wiegand Signal | Input, Output |
| Aux. Input | 1 ea for linkage function |
| Function | DST, Automatic Status Switch, Record query, T9 input, 14 digit user ID, Anti-passback, Scheduled-bell, Printer(optional), ADMS (optional) |
| Power Supply | 12 VDC, 3A |
| Operating temperature | 0°C - 45°C |
| Operating Humidity | 20% - 80% |
| Dimension(W×L×H) | 158.5 x 78.0 x 19.4 mm |
| SDK and Software | Standalone SDK, ZKAccess 3.5 |
